Inconel 800
Inconel 800 Rods Manufacturers, Alloy 800 Sheet Exporters, Incoloy Alloy 800H / 800HT Round Bars, Inconel 800 Bars Suppliers in India.
Mahendra Metals & Tubes Company is one of the well-established trading house and supplier ofInconel 800 Round Bars , which can be formed using various cold and hot working processes. Although it tends to work harden it can be cold formed using the more aggressive methods such as deep-drawing, press forming or punching.
Inconel 800 Flat Bars of Mahendra Metals & Tubes Company is the alloy for outstanding performance in a range of aggressive environments, which is further resistant to strong oxidizing chlorides, reducing acids, hot seawater and brine solutions. Hot forming should be performed within a temperature range between 1600 Degree F and 2250 Degree F (870 Degree C – 1230 Degree C) with heavier sections heated to a minimum of 2000 Degree F before forming.
Inconel 800 Hex Bars of Mahendra Metals & Tubes Company is known as the most universally corrosion resistant material available today, and is also used in a variety of environments from moderately oxidizing to strong reducing conditions.
They are versatile austenitic nickel-chromium-molybdenum-tungsten alloy, where parts which have been hot-formed should be solution heat - treated prior to final fabrication or installation, if possible. A prime advantage of Inconel 800 Sheets is that it generally does not require solution heat treatment after welding, where further it also resists the formation of grain boundary precipitates that would degrade corrosion resistance. Inconel 800 Plates of Mahendra Metals & Tubes Company is one of the most corrosion-resistant steels in the world.
UNS N08800 Incoloy Alloy 800 Plates Distributor, Incoloy 800H Round Rods, WNR 2.4876 Incoloy 800 Steel Bars, Alloy 800HT Strip Dealers in India.
Inconel Alloy 800 Specification
| STANDARD | Incoloy Alloy 800 / 800H / 800HT |
| WERKSTOFF NR. | W.Nr 2.4876 |
| UNS | N08800 / N08810 / N08811 |
| Bars | ASTM B408 |
| Sheets & Plates | ASTM B409 |
| Forging | ASTM B564 |
| Fittings | ASTM B366 |
| Applications | Chemical Industry, Oil and Gas, Chemical & Hydrocarbon Processing Equipment, Food processing, Industrial Heat Exchangers, Pulp and paper industry, Nuclear Engineering etc. |
Chemical Composition for Incoloy Alloy 800 UNS N08800
| Fe | Al | Cr | Al+Ti | Ni | C | Ti |
| 39.5 min | .15-.60 | 19.0-23.0 | .30-1.20 | 30.0-35.0 | .10 max | .15-.60 |
Chemical Composition for Incoloy Alloy 800H UNS N08810
| Fe | Al | Al+Ti | C | Ti | Cr | Ni |
| 39.5 min | .15-.60 | .30-1.20 | .05-.10 | .15-.60 | 19.0-23.0 | 30.0-35.0 |
Chemical Composition for Incoloy Alloy 800HT UNS N08811
| Fe | Cr | Ti | Al+Ti | Al | C | Ni |
| 39.5 min | 19.0-23.0 | .25-.60 | 0.85-1.2 | .25-.60 | .06-.10 | 30.0-35.0 |
Mechanical Properties UNS N08800 Alloy Inconel 800, 800H, 800HT Rod & Bar
| Product | Tensile (ksi) | .2% Yield (ksi) | Elongation (%) |
| Rod & Bar | 75-100 | 30-60 | 60-30 |
